- 支持USB 2.0
- 总线供电
- 8 通道模拟输入
- 12位分辨率AI
- 采样率达10 kS/s
- 8通道数字输入/8通道数字输出, 2通道模拟输出和一个32位计数器
USB-4702 is a low-cost USB data acquisition module. You no longer need to open the chassis to install DAQ modules. Just plug in the module, then get the data. It’s easy and efficient. Reliable and rugged enough for industrial applications, yet inexpensive enough for home projects, USB-4702 is the perfect way to add measurement and control capability to any USB capable computer. It obtains all required power from the USB port, so no external power connection is ever required. With the features of USB-4702, it is your most cost effective choice of lab or production line test measurement tool.
规格
- Part Number
- 相关讯息
- USB-4702-AE
- Sampling Rates(S/s)
- Resolution(Bits)
- Bipolar Inputs (V)
- Channels
- Type
- 10k
- 12
- Single-ended: ±10; Differential: ±1, ±1.25, ± 2, ± 2.5, ±4, ±5, ±10, ±20
- 8
- Scan
- Resolution(Bits)
- Channels
- Update Rate(kS/s)
- 12
- 2
- Static
- Power Consumption
- I/O Connectors
- Bus
- Dimensions
- Operating Temperature
- OS Support
- Programming Language
- Typical: 5V @ 100 mA; Max.: 5 V @ 500 mA
- 1 x DB37 female connector
- USB 2.0
- 70 x 70 mm (2.76 x 2.76)
- 0 ~ 55°C (32 ~ 131°F)
- 32-bit/64-bit Windows 7/8/10, and Linux
- C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt
- Resolution
- Max. Input Frequency
- Channels
- 32 bits
- 5 MHz
- 1
- Input Channels
- Output Channels
- 8
- 8
